The Eagle Eye Cloud VMS and its bridge hardware is specifically designed to be highly secure and only uses utilizes TCP and UDP connections to transmit data to the cloud. If you restrict outbound connections on your local firewall, here is the IPv4 and port information you will need.

There can be no proxies or similar application-layer filtration devices between the Eagle Eye Bridge and the Internet, and multicast must be enabled so the bridge can detect cameras (if the bridge and cameras are on the same subnet, generally this isn’t a problem). UPNP is NOT required (the bridge won’t use it if enabled).
For further information on the ONVIF camera discovery protocol we use, see this article on WS-Discovery. Web Service Discovery is an OASIS industry standard and generally works without much effort on most internal networks. You should not need to adjust your firewall to get it to work unless there are additional firewalls between your bridge and cameras

Outbound Ports for the Eagle Eye Bridge

The following TCP and UDP ports are used by the Eagle Eye Bridge. All connections are outbound-only, meaning that the bridge connects outbound and never accepts inbound connections (generally, you do NOT need to set up NAT rules).

80/TCP                                                 # Used to discover video termination endpoints in the cloud

443/TCP                                              # Used to transfer video to the cloud (TLS 1.2+)

773/TCP                                              # Used to transfer video to the cloud (TLS 1.2+)

8081/TCP                                            # Used occasionally to test video transfer to the cloud

8082/UDP                                           # Used to transfer video metadata to the cloud

50000-60000/TCP                             # Used occasionally to provide remote troubleshooting and maintenance
                                                                      (Secured via SSL)

Ports 80 and 443 are utilized for firmware management. If these ports are filtered or blocked it can cause failed updates for our systems.
Ports 8081 and 8082 are utilized for the preview stream. If this port is filtered or blocked it will impact the preview stream stability and quality.
Eagle Eye utilizes standard ports for our troubleshooting tools. (Ex. Ncat and Fping) These may show as being utilized on your network, but rest assured they are only for system maintenance.

Outbound IPs for the Eagle Eye Bridge

Should you need to restrict the Eagle Eye Bridge to a specific set of IP addresses, the following is the list of Eagle Eye IP addresses you should allow, in CIDR format:


IPs
209.94.248.0/26
208.81.96.0/22
216.245.88.0/21
61.120.148.0/25
210.248.158.0/24
218.102.54.64/26
223.197.211.0/25
199.204.51.0/25
62.50.13.192/27
195.81.164.160/27
89.202.213.96/28
167.248.134.0/23
167.94.38.0/23
167.94.228.0/23
192.40.4.0/23
199.45.160.0/22


Ensure that your Firewall has our DNS sites whitelisted as well. Those sites are as follows:
*.eagleeyenetworks.com
*.plumv.com
*.eencloud.com


Outbound Ports for the Eagle Eye Web and Mobile Applications

Independent of the bridge, the Eagle Eye Web and Mobile Applications for PCs, tablets, and phones also need to connect to the cloud to retrieve video, set settings, and so on. The ports required for this are:

80/TCP                                     # HTTP -> SSL Redirect Only

443/TCP                                   # Web user interface

50000-60000/TCP                # Secure video transfer

The IP addresses are generally the same as for the bridge.


Outbound Ports for CameraDirect

Camera Direct uses the following TCP ports. All connections are outbound-only, meaning that connections are outbound and never accept inbound connections (so you do NOT need to set up e.g. NAT rules as a general rule).

80/TCP                                # Used to discover video termination endpoints in the cloud

443/TCP                              # Used to discover video termination endpoints in the cloud

8181/TCP                            # Used to transfer video to the cloud


Eagle Eye Camera Direct Subnets
dispatch1v1.eagleeyenetworks.com (167.248.134.73)
dispatch2v1.cameramanager.com  (167.248.135.100)
dispatch2v1.eagleeyenetworks.com (167.248.135.100)
192.40.4.124
192.40.5.26

Apart from these, the IP’s which are used by “Outbound IPs for the Eagle Eye Bridge”, also need to be allowed.

Eagle Eye utilizes the 2.centos.pool.ntp.org server for NTP. Usually through port 123 as is the standard.
