CameraManager Firewall Configuration
CameraManager Firewall Configuration
2024-05-13
Version 2.0
The following TCP and UDP ports are used by the Eagle Eye CameraManager. All connections are outbound-only, meaning that connections are outbound and never accept inbound connections (so you do NOT need to set up e.g. NAT rules as a general rule).
TCP 80 | Used to discover video termination endpoints in the cloud |
TCP 443 | Used to discover video termination endpoints in the cloud |
TCP 554 | Used for PnP1 video transmission of old PnP1 cameras |
TCP 1080 | Used for PnP1 data connection of old PnP1 cameras |
TCP 8181 | Used to transfer video to the cloud |
TCP 8282 | Used to transfer video to the cloud |
TCP 5448 | Used for transmission of motion events of old cameras |
TCP 1935 | Used for RTMP of old cameras |
TCP 25 | Used for SMTP event transmission of old PnP1 cameras |
UDP 50000-51000 | RTP port range |
Eagle Eye Camera Manager Subnets:
208.81.96.0/22 |
192.40.4.0/23 |
167.248.134.0/23 |
37.58.51.0/25 |
62.50.13.192/27 |
195.81.42.160/27 |
195.81.164.160/27 |
154.14.108.192/27 |
89.202.212.160/28 |
89.202.213.96/28 |
212.23.62.240/28 |
216.245.93.0/27 |
![](https://static.zohocdn.com/zoho-desk-editor/static/images/info.png)
![](https://lh7-us.googleusercontent.com/n48cXlVILWp8EyM4rNCm5ajtWZw7958HG9hRSpS9nuop6Y6viaYWYdFcRqYa21Rb6DdAqGuJCoJQdkU5qmDUTLc4r687wouB7Wz0b5K187OZJwmz20eE4_JWGiebYGC3qN6Pw_P4XWCNnfZROnPJiMo)
For support please email: support@een.com
or give us a call at: 512-473-0501
